Humanity HM-S102 STM1 electrical and optical converter is widely used in SDH network. This is electrical and optical converter with 155.52Mbps.

• Compact design
• Stable performance with strict test.
• Offer standard optical and electrical interface with two loopback functions to test the connection.
• Easy installation and maintenance.

STM-1 electrical	STM-1 optical
Comply with ITU-T G.703Rate: 155.52MbpsLine code: CMIConnector: BNC	Rate: 155.52MbpsComply with ITU-T G.957Light source: Laser DiodeWavelength: 1310nm or 1550nmCodification: NRZFC/SC option
LED indicators	Power& Environment
PWR2XLOS: one for electrical and the other for optical2XOOL: one for electrical and the other for optical	AC, DC or AC+DC powerWorking temperature: 0 ~ 50℃Relative humidity: ≤95%, non-condensingPower consumption: <5W
